Skraper 3.6m (Dubbel-Wiel) | Grader 3.6m (Double-Wheel)

Skraper 3.6m (Dubbel-Wiel) | Grader 3.6m (Double-Wheel) | V016

VZS se Skraper 3.6m Dubbel-Wiel bou en skraap kontoere en paaie met volle hidroliese beheer — slegs die trekkeroperateur word benodig. | VZS’s 3.6m Double-Wheel Grader builds and scrapes contours and roads with full hydraulic control — only the tractor operator is required.

Description

Inligting

· Voldoende trekker: vanaf 150kW
· Lembreedte: 3,600mm
· Lem draai meganies met draaiskamel — 5 verstelbare punte
· Gewig: 4,200kg
· Bande: 305/55/R22.5
· Kantel-haak (Swivel)
· Betonblokke agter op wiele vir optimale gewigsverplasing
· Kan tot 30° kantel

Komponente

· 5 Hidroliese punte
· Gebou met dubbelraam
· Silinders by die wiele — onafhanklik verstelbaar vir lemhelling
· Alle verstellings vanuit die trekker

Werking

· Vir die bou en skraap van kontoere en paaie
· Slegs 1 operateur benodig — alle verstellings hidrolies

Specifications

· Tractor requirement: from 150kW
· Blade width: 3,600mm
· Blade rotates mechanically via swivel with 5 adjustable points
· Weight: 4,200kg
· Tyres: 305/55/R22.5
· Swivel hitch
· Concrete blocks on rear wheels for optimal weight transfer
· Tilts up to 30°

Components

· 5 Hydraulic points
· Built with double frame
· Cylinders at the wheels — independently adjustable for blade angle
· All adjustments from the tractor cab

Operation

· For building and scraping contours and roads
· Only 1 operator required — all adjustments hydraulic
